Product Summary
The NLV32T-150J-PF is a renewed version of NL322522. It is a SMD inductor(Coils) for signal line(Wound). The product has good heat durability that withstands lead-free compatible reflow soldering conditions. It uses metal terminals, which realize excellent connection reliability. The NLV32T-150J-PF is applied in audio-visual equipment including TVs, VCRs and digital cameras. It is also applied in electronic equipment used in communication infrastructures and other electronic equipment including HDDs and ODDs.
Parametrics
Specifications and iron soldering: (1)Operating temperature range:–40 to +105°C [Including self-temperature rise] ; (2)Storage temperature range: –40 to +105°C; (3)Tip temperature: 300 to 350°C; (4)Heating time: 3 seconds/soldering; (5)Soldering rod specifications: Output: 30W Tip diameter: 1mm; (6)Packaging style:T Taping (reel).
Features
Features: (1)This is a renewed version of NL322522; (2)The product has good heat durability that withstands lead-free compatible reflow soldering conditions; (3)Lead-free material is used for the plating on the terminal; (4)The electrical characteristics, reliability, shape and pad shape are the same as the previous NL series; (5)The product uses metal terminals, which realize excellent connection reliability; (6)Highly heat resistant thermoplastic resin is used to form the exterior package; (7)From 001μH to 470μH, all of the products in the E-12 series are J(±5%) tolerance products; (8)This product is in compliance with the RoHS Directive Other products with specifications that do not include exemption regulations are also available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 NLV32T-150J-PF |
TDK |
Common Mode Inductors (Chokes) 15uH 5% |
Data Sheet |
|
|
||||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||||
|
NLV32T-010J-PF |
TDK |
Common Mode Inductors (Chokes) 0.01uH 5% |
Data Sheet |
|
|
||||||||||||||
|
NLV32T-012J-PF |
TDK |
Common Mode Inductors (Chokes) 12uH |
Data Sheet |
|
|
||||||||||||||
|
NLV32T-015J-PF |
TDK |
Common Mode Inductors (Chokes) 0.015uH 5% |
Data Sheet |
|
|
||||||||||||||
|
NLV32T-018J-PF |
TDK |
Common Mode Inductors (Chokes) 18nH 5% |
Data Sheet |
|
|
||||||||||||||
|
NLV32T-022J-PF |
TDK |
Common Mode Inductors (Chokes) 0.022uH 5% |
Data Sheet |
|
|
||||||||||||||
|
NLV32T-027J-PF |
TDK |
Common Mode Inductors (Chokes) 27 NH 5% |
Data Sheet |
|
|
||||||||||||||
